CETATEST XS
The CETATEST XS is a compact, cost-effective and full automatically working leak tester for the detection of untight parts within the cycle time of the production process. The leak tester uses a gauge pressure sensor for the measurement of the pressure loss caused by the leakage in the test part. Suitable for the leak-testing of small-volume test parts and short total testing times Measurement range up to 10,000 Pa
| Specification | Details |
|---|---|
| Pressure Sensor | Gauge pressure sensor |
| Pressure Ranges | Internal electronically regulated: -1 bar / +1 bar, 0.010 – 0.200 bar, 0.020 – 1.000 bar, 0.20 – 8.00 bar (external pressure regulation as an option) |
| Measurement Ranges | ±2,500 Pa, ±9,999 Pa / ±25.0 hPa, ±99.9 hPa (depending on the pressure range) |
| Result Units | Pa, hPa (pressure loss), bar (test pressure) |
| Test Mode | Pressure decay |
| Dimensions (W×H×D) | 280 mm × 96 mm × 250 mm |
| Typical Applications | Leak tests requiring a large measuring range |
